V94.2
HEAVY-DUTY GAS TURBINE
Specifications
| Power output | 198 MW |
| Fuel (examples) | Natural gas, LNG, sour gases, distillate oil, biodiesel, crude oil, heavy fuel oil (HFO), kerosene, jet fuel, condensate. Other fuels on request |
| Frequency | 50 Hz |
| Gross efficiency | 37.6% |
| Heat rate | 9,863 kJ/kWh (9,863 Btu/kWh) |
| Turbine speed | 3,000 rpm |
| Pressure ratio | 12.8 : 1 |
| Exhaust mass flow | 558 kg/s (1,230 lb/s) |
| Exhaust temperature | 536°C (997°F) |
| NOₓ emissions | ≤ 25 ppmvd at 15% O2 on fuel gas (without water injection for NOₓ control), ≤ 42 ppmvd at 15% O2 on fuel oil (with water injection for NOₓ control) |
